Dwyer - CS-30
| Manufacturer | Dwyer |
|---|---|
| Part Number | CS-30 |
| Inner Code | 4287712 |
| Description | Diaphragm Pressure Switch |
| Technical specification | (1-30 psig) Wetted Materials: Nylon reinforced Buna-N and steel Temperature Limits: -30 to 150°F (-35 to 66°C) Pressure Limit: 30 psig (2.1 bar) for ranges 1, 3, and 10. 50 psig (3.5 bar) for range 30. 175 psig (12.1 bar) for range 150 Enclosure Rating: General purpose Switch Type: SPDT snap switch Electrical Rating: 15 A @ 120 VAC, 8 A @ 240 VAC Electrical Connections: Screw terminal Conduit Connection: 1/2" hole for conduit hub Process Connection: 1/4" female NPT Mounting Orientation: Any position Set Point Adjustment: Internal screw |
Please contact us to request a price quote for Dwyer - CS-30, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
