Dwyer - 616W-3M-LCD
| Manufacturer | Dwyer |
|---|---|
| Part Number | 616W-3M-LCD |
| Inner Code | 4289220 |
| Description | Weatherproof Differential Pressure Transmitter (0-2.5 kPa) with LCD |
| Technical specification | Service: Air and non-combustible, compatible gases. Accuracy: ±0.25% F.S., display accuracy ±0.5%. Stability: ±1% F.S./yr. Temperature Limits: 0 to 140°F (-17.8 to 60°C). Compensated Temperature Limits: 20 to 120°F (-6.67 to 48.9°C). Pressure Limits: 34.5 kPa. Thermal Effect: ±0.02% F.S./°F (0.0012% F.S./°C). Power Requirements: 10-35 VDC (2-wire). Output Signal: 4 to 20 mA. Zero and Span Adjustments: Potentiometers for zero and span. Loop Resistance: DC; 0-1250 ohms maximum. Current Consumption: DC; 38 mA maximum. Electrical Connections: Screw-type terminal block. Process Connections: Barbed, dual size to fit 1/8" and 3/16" (3.12 mm and 4.76 mm) I.D. rubber or vinyl tubing. Enclosure Rating: NEMA 4X. Mounting Orientation: Vertical, consult factory for other position orientations. Weight: With LCD 9.6 oz (272 g). Agency Approvals: CE. |
Please contact us to request a price quote for Dwyer - 616W-3M-LCD, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
