Dwyer - 1823-20
| Manufacturer | Dwyer |
|---|---|
| Part Number | 1823-20 |
| Inner Code | 4262075 |
| Description | Low Differential Pressure Switch |
| Technical specification | Operating Range 3 to 22" w.c. Approximate Deadband At minimum set point: 0.35 At maximum set point: 0.70 Service Air and non-combustible, compatible gases Temperature Limits -30 to 180°F (-34 to 82.2°C) Pressure Limits 10 psig (68.95 kPa) continuous, 25 psig (172.4 kPa) surge Switch Type Single-pole double-throw (SPDT) Repeatability ±2% Electrical Rating 15 A at 120 to 480 VAC, 60 Hz Resistive 1/8 HP at 125 VAC, 1/4 HP at 250 VAC, 60 Hz De-rate to 10 A for operation at high cycle rates |
Please contact us to request a price quote for Dwyer - 1823-20, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
