Demag - ZBA 80 A 8 B007 H 1
| Manufacturer | Demag |
|---|---|
| Part Number | ZBA 80 A 8 B007 H 1 |
| Inner Code | 5007159 |
| Technical specification | cylinder rotor motor The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall under the scope of the EuP Directive. Technical data: Motor speed 830 rpm Power 0.22 kW Operating time 60% Motor protection class IP 54 Ambient temperature -20... +60 °C Installation height ≤ 1000 m Design wrench ZBA 80 A 8 B007-H-1 Type H Terminal box position on the right, 1 Horizontal motor installation position Total net weight approx. 15 kg Electrical data: Supply voltage D/Y 250/440 V Line frequency 60 Hz Current D/Y 2,00/1,10 A Brake technical data: Braking torque 1,3 Nm Voltage 50 V DC Current 0.44 A with brake rectifier GE 110 V AC equipment: 3 cold conductors for shutdown at 160 °C with varistor protection with phase insulation for inverter operation D/Y motor circuit with sprocket for direct attachment to A60T i=297.00 Light fan disc selected ambient temperature: 60° C Warmth class F Warmth class F abnormal brake tension Execution exactly as order number: 29600200 from 2006 color scheme: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive |
Please contact us to request a price quote for Demag - ZBA 80 A 8 B007 H 1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
