Demag - EUDC-Pro 16-1600 1/1 H4 V9.6/2.4
| Manufacturer | Demag |
|---|---|
| Part Number | EUDC-Pro 16-1600 1/1 H4 V9.6/2.4 |
| Inner Code | 4266621 |
| Description | Demag Monorail hoist |
| Technical specification | 380-400/60 14.4/4.8 200 400 The Demag DC-Pro chain hoist meets all the requirements of a Demag brand quality product and sets standards for industrial hoists. It is a highly versatile chain hoist, which can be installed and put into service in a minimum of time. The DC-Pro features highly convenient operation, high productivity, optimum utilisation of the available height and maximum reliability and meets the efficiency and safety-relevant requirements of a state-of-the-art hoist unit. The standard scope of delivery includes the following equipment: - Modular contactor control with 24V control voltage (with internal tri-state signal transmission) - A geared limit switch for internal signal evaluation with 4 contacts as an operating limit switch for fast-to-slow and final cut-off designed for reliable switch-off of the chain hoist at its limit position - An elapsed operating time counter that can be read from the outside - Two standard hoist speeds as the main and creep lifting speeds - The speed-monitored braking and clutch principle provides for a high level of safety, reliability and a long service life - Gearbox and slipping clutch are maintenance-free for up to 10 years, the brake for up to 5 years - For service purposes, the operating parameters can be read out from the chain hoist control system via an optical display or wirelessly by means of the integrated infrared diagnostic interface - All electric connections of the chain hoist are of plug-and-socket design - A central service enclosure that provides direct access to all important plug-and-socket connections and simple chain lubrication - Fast and simple replacement of the chain drive without having to remove the motor or gear parts Power supply Operating voltage 400 V Line frequency 60 Hz Power supply type 3-phase Chain hoist technical data Load capacity 1600 kg FEM/ISO group 2m+ / M5+ (20% more than 2m / M5) Hook path 4 m Control cable length 0.8 - 2.8 m Weight approx. 110 kg (net total) Reeving 1/1 Lifting speeds approx. 9.6/2.4 m/min Control voltage 24V AC Hoist unit voltage 380-400 V/ 60 Hz Hoist motor ZNK 100 B 8/2 Duty factor 40 / 20 % Rated power 2.61 / 0.65 kW Type of enclosure IP 55 Insulation class F Ambient temperature -20 °C to +45 °C C-dimension 640 mm Surface protection and paint finish Hoist unit colour RAL 5009 azure blue High quality powder-coating of the aluminum components of the chain hoist provide a very good protection against corrosion. Chain collector Standard chain collector box rated for 4 m hook path Trolley - The trolley is infinitely adjustable to the relevant flange width - Trolley fitted as standard with drop stops and lateral guide rollers to protect the runway and trolley travel wheels - Integrated lift-off protection - Universal travel wheels for profile-section girder Trolley technical data Type EU56-200 Flange width 98 - 200 mm Max. flange thickness 30 mm Min. flange height 128 mm Travel motor - 2 driven travel wheels - pole-changing three-phase motor - VGZ dual-output gearbox for double-wheel drive - Controlled by the crab module under the chain hoist electric equipment cover Technical data for cross-travel motor Travel speeds 14.4/4.8 m/min Travel motor ZBF 80 A 12/4 Duty factor 40 / 15 % Rated output for travel motor 0.25 / 0.06 kW Rated current 0.97 / 1.5 A Motor speed 1380 / 415 minˉ¹ The electric-travel chain hoist is supplied in sub-assemblies. These have to be assembled by the customer. Sub- assamblies consists of: - DC chain hoist - Trolley / travel motor Control unit Control cable with control pendant Control pendant: DSC-5 Control cable: height-adjustable standard control cable 0.8 - 2.8 m Further selected options - Support roller fitting Documentation - EU documents according to Machinery Directive |
Please contact us to request a price quote for Demag - EUDC-Pro 16-1600 1/1 H4 V9.6/2.4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
