Demag - DIC-4-007-E-0000-03
| Manufacturer | Demag |
|---|---|
| Part Number | DIC-4-007-E-0000-03 |
| Inner Code | 560892 |
| Description | Demag frequency inverter Ddrive Compact STO |
| Technical specification | Translation types Text translation Source text 3849 / 5000 Translation results Digital two-point inverter with voltage intermediate circuit for one- and four-quadrant operation with integrated Brake chopper for resistance braking. Integrated safety function "Safe Torque Off" (STO) according to EN 61800-5-2. Fulfills the requirements Cat.3, PLd according to EN ISO 13849-1 and SIL2 according to IEC 61508. The Dedrive Compact STO frequency inverter has many excellent performance features that make it suitable for predestine diverse applications. Whether lifting, lowering, rotating, driving or swiveling, the Dedrive Compact With its many functions and options, STO enables a wide range of applications. The Dedrive Compact STO enables cylinder and conical rotor motors to be controlled and adapted to Your specific workflow. Jerk-free acceleration and gentle deceleration ensure a gentle ride Transport and reduce load swaying in cranes, among other things. In addition, by using the Dedrive Compact STO motors and gearboxes are relieved and the mechanics are protected against increased wear. A line filter is already integrated in the frequency inverters DIC-4-002 to DIC-4-017. So meet the mentioned Frequency converters up to a motor cable length of 10 m meet the emission limit values in accordance with the product standard EN 61800-3. Additional external filters are optionally available for longer cable lengths. Commissioning can be carried out in relatively few steps, either through the Control unit KP 500 or with the help of the Parcom Compact parameterization software. Technical specifications: Mains voltage: 3 x 380 - 480 V (+ 10 / -15%) Mains frequency: 50/60 Hz (+ 10 / -10%) Motor shaft power: 3.00 kW Output voltage: 3 x 0 - mains voltage V Output frequency: 0 - 300 Hz depending on the switching frequency Output current: 7.8 A at 2 to 8 kHz Overload factor at 2 and 4 kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (note current reduction) Protection class: IP 20 Operating temperature: 0 - 40 ° C Installation altitude: 0 - 1000 m Dimensions: 60/250/175 mm width / height / depth Installation position: vertical Weight, net approx .: 1.7 kg Technical data in the operating point Mains voltage: 3 x 400 V Output current: 7.8 A at 40 ° C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 ° C / 40 ° C Installation altitude: 0/1000 m Description of the device: - Integrated safety function "Safe torque off" (Safe Torque Off, STO) according to EN 61800-5-2 - Integrated brake chopper - Motor output earth fault and short circuit proof - Optional U / f characteristic or field-oriented control (FOR with or without encoder) - Motor protection via motor thermal contact - 1 slot for a control unit - 1 slot for a communication module - 1 slot for an expansion module - Parameterization via optional serial interface RS 232 and PC or optional keypad (control unit) - Switchable modulation frequencies - fault memory - Basic device without control unit Configurable inputs / outputs: - 6 digital inputs, 1 multifunctional input (analog / digital) - 1 relay output, 1 multifunction output (analog / digital) - 1 digital transistor output 24V Specification: Type: Dedrive Compact STO DIC-4-007-E-0000-03 - KP 500 keypad (control unit) - CD-ROM 21368644 (configuration guide and further product documentation) Note: A line filter is already integrated in the frequency inverters DIC-4-002 to DIC-4-017. So meet the mentioned Frequency converters up to a motor cable length of 10 m meet the emission limit values according to the product standard EN 61800-3. Additional external filters are optionally available for longer cable lengths. Documentation: Brief operating instructions / project planning guidelines and further product documentation on CD-ROM More about this source text Source text required for additional translation information Send feedback Side panels |
| Weight | 1 |
Please contact us to request a price quote for Demag - DIC-4-007-E-0000-03, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
