Demag - DIC-4-006-E-0000-03
| Manufacturer | Demag |
|---|---|
| Part Number | DIC-4-006-E-0000-03 |
| Inner Code | 251712 |
| Description | Dedrive Compact STO frequency inverter |
| Technical specification | Replaced Material No 16040084 Demag Dedrive Compact STO frequency inverter Digital two-point inverter with voltage intermediate circuit for one and four-quadrant operation with integrated brake chopper for resistance braking. Integrated safety function “Safely switched off moment” (Safe Torque Off, STO) in accordance with EN 61800-5-2. Meets the requisitions Cat.3, PLd according to EN ISO 13849-1 and SIL2 according to IEC 61508. Technical data: Line voltage: 3 x 380 - 480 V (+10/-15%) Line frequency: 50/60 Hz (+10/-10%) Motor shaft power: 2.20 kW Output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 5.8 A at 2 to 8kHz Overload factor at 2 and 4kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (Note the power reduction Integrated safety function “Safely switched off moment” (Safe Torque Off, STO) in accordance with EN 61800-5-2. Meets the requirements of Cat.3, PLd according to EN ISO 13849-1 and SIL2 in accordance with IEC 61508. Technical data: Line voltage: 3 x 380 - 480 V (+10/-15%) Line frequency: 50/60 Hz (+10/-10%) Motor shaft power: 2.20 kW Output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on switching frequency Output current: 5.8 A at 2 to 8kHz Overload factor at 2 and 4kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (current reduction notice Protection class: IP 20 operating temperature: 0 - 40 °C Installation height: 0 - 1000 m dimensions: 60/250/175 mm width/height/depth Installation position: vertical Net weight: approx. 1.7 kg Technical data at operating point Line voltage: 3 x 400 V Output current: 5.8 A at 40 °C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C Installation height: 0/1000 m Specification: Type: Dedrive Compact STO DIC-4-006-E-0000-03 - Keypad KP 500 (control unit) |
| Weight | 1 |
Please contact us to request a price quote for Demag - DIC-4-006-E-0000-03, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
