Demag - DC-PRO 5-500 1/1 H5 V8/2
| Manufacturer | Demag |
|---|---|
| Part Number | DC-PRO 5-500 1/1 H5 V8/2 |
| Inner Code | 4700040 |
| Custom Code | 84251100 |
| Technical specification | 380-415/50 supply network Line voltage 400 V Line frequency 50 Hz Network type three-phase 3-phase Technical data chain hoist Load capacity 500 kg FEM/ISO group 2m+/M5+ (20% more than 2m/M5) Hook path 5 m Control cable length 0.8 - 3.8 m Weight approx. 30 kg (total net) 1/1 shear Lifting speed approx. 8/2 m/min Control voltage 24V AC Hoist voltage 380-415 V/ 50 Hz ZNK 80 B 8/2 lift motor duty cycle 40/20% Rated power 0.73/0.18 kW Protection class IP 55 Insulation class F Ambient temperature -20 °C to +45 °C C size 416 mm |
Please contact us to request a price quote for Demag - DC-PRO 5-500 1/1 H5 V8/2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
