DAYTON - 30PT89
| Manufacturer | DAYTON |
|---|---|
| Part Number | 30PT89 |
| Inner Code | 4293904 |
| Technical specification | MTR,CS/CR,ODP,3/4 HP,3450,56,EFF 76.2 Motor Design: Capacitor-Start/Run Phase: Single HP: 3/4 RPM Range: 3,001-3,600 Voltage Compatibility: 115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC Frame: 56 Voltage: 115/230V AC Motor Thermal Protection: Auto Motor Enclosure Design: Open Dripproof Motor Mounting Type: Cradle Base Full Load Amps: 7.0/3.6 Nameplate RPM: 3,450 Shaft Length: 1 7/8 in Motor Bearings: Ball Duty: Continuous Green Certification or Other Recognition: Energy Aware Max. Ambient Temp.: 40 Degrees C Nominal Efficiency: 76.2 % RPM Group: 3001-3600 Motor Frame Material: Rolled Steel Motor Shaft Design: Keyed Motor Mounting Position: Horizontal No. of Speeds: 1 Motor Efficiency Group: Premium Efficient Includes: Start Cap 357MFD @ 165V Manufacturers Warranty Length: 1 yr Overall Length: 11 13/16 in Ins. Class: B Hz: 60 Shaft Dia.: 5/8 in Standards: CSA (258501), UL (E47479) Green Environmental Attribute: Product Contributes To Reducing Energy Consumption Frame Material: Rolled steel Motor Service Factor: 1.25 Length Less Shaft: 9 7/8 in Motor Application: General Application Motor Shaft Rotation: CW/CCW Inverter Rated: No Duty Cycle: Continuous Zoro Benefits: 7,000+ Brands. Free Shipping. Hassle Free Returns. |
Please contact us to request a price quote for DAYTON - 30PT89, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
