Contelec - 31E6b736125602
| Manufacturer | Contelec |
|---|---|
| Part Number | 31E6b736125602 |
| Inner Code | 4947382 |
| Description | Encoder |
| Technical specification | Mechanical version Magnetic actuator type 6 Mounting hole Through hole ø4.4 mm, counterbore ø7.4 mm Sensor principle MH-C Electrical angle Electrical angle 360° Voltage 24VDC Output signal 0.5 VDC to 4.5 VDC Output characteristics Redundant, cross signal curve Electrical connection Round cable, 6 poles Cable length 1.0 m (cable) electrical data Measuring range ° 0…360 Independent directness (typical) Measuring range (%) ±0.3 Hysteresis maximum value ° 0.1 resolution bit 12 Maximum repeatability ° 0.1 Sample rate, fast mode kHz (5) Sample rate, slow mode kHz 1.66 System propagation delay, fast mode μs (800) System propagation delay, slow mode μs 4600 Maximum temperature coefficient, output signal ppm/K 100 MTTFd / MTBF on request Voltage VDC 8…35 No-load current consumption (typical), fast mode, mA per channel (19) No-load current consumption (typical), slow mode, mA per channel 14 Minimum ohmic load, output kOhm 10 Maximum capacitive load on output side nF 100 Power supply reverse polarity protection Yes Electrical connection Round cable, 6 poles Solid wire cross section mm² 0.25 (AWG24) machine data Mechanical range ° 360 (continuous) Protection rating IP68 Minimum lifespan No limit Operating temperature/storage temperature °C -40…+85 EN 60068-2-6, Vibration (Amax = 0.75 mm, f = 5–2,000 Hz) g 50 EN 60068-2-27, impact g 200 |
Please contact us to request a price quote for Contelec - 31E6b736125602, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
