Cewe - DPT623-157

Manufacturer Cewe
Part Number DPT623-157
Inner Code 3824297
Description Programmable reactive power transmitter
Technical specification for 3-phase connection Measuring current: 1/5 A Measuring voltage: 3 x 57.5 — 240 V (conductor-earth) Frequency: 50/60 Hz 2 x outputs:... 20 mA Auxiliary voltage: 80 - 276 V AC/DC with mini USB port Accuracy class: 0.5 according to IEC 688-2
Weight 1

Please contact us to request a price quote for Cewe - DPT623-157, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Cewe-DPT623-157 price

More products of Cewe

  • W 375243111

    Multifunctional, programmable energy meter

  • -5...0...+ 5 MVAR

    MVAR Meter,96x96 Panel Mounting,4... 20ma Size: 96 x 96, Excitation panel of Syn.Motor

  • ART. 379891001

    Door installation CewePrometer W

  • AUF SEITE 35 DES KATALOGS M-TECH

    (Highlighted), please offer its equivalent, but produces CEWE.

  • C 563 - OBSOLETE, REPLACEMENT - DPT521- 401

    C 563 AC/DC 85-230 V 50/60Hz 7 VA

  • CEWEPROMET ER W 372843110

    Multifunctional, programmable energy meter (Four-quadrant counter, class 1 for the active energy according to IEC62052-11 & IEC62053-21, reactive energy in Accuracy of 2%, bidirectional, two elements 4 Ladder network 4 pulse inputs, 8 pulse outputs, Basic functions, tariffs, peak detection, Load profile memory, optical Communication Interface) Current: 3 x 150/5 A Voltage: 3 x 6600/110 V :: frequency 50 Hz Auxiliary power supply: 40-276 V AC / DC for mounting plate assembly Pulse rate: 10 kWh per pulse or kVArh Display in English

  • CL48

    (instrument with moving coil Quadrant with scale 240 ° pointer deflection Front size: 48 x 48 mm Input: 4-20 mA Scale: 0-100% with terminal cover)

  • CL96

    Drehspulmessinstrument

  • CONFIG VIEW SUITE

    One software configuration licence & one communication cable

  • CONFIGVIEW

    ConfigView (Software + Cable) Software for programming and reading of DPT

  • CP23 T1 DP135

    FORCE TRANSDUCER (P)

  • CP23 T2 DP135

    FORCE TRANSDUCER (P)

  • CP28-U10 P2 CQ48

    The voltmeter

  • CQ72

    (instrument with moving coil Quadrant scale with 90 ° deflection of the pointer, Front size: 72 x 72 mm Input: 0-150 V, DC Scale: 0-150 V Accuracy class 1.5 with terminal cover)

  • CQ72

    (instrument with moving coil Quadrant scale with 90 ° deflection of the pointer, Front size: 72 x 72 mm Input: 0-40 V, DC Scale: 0-40 V Accuracy class 1.5 with terminal cover)

  • CQ72

    instrument with moving coil Quadrant scale with 90 ° deflection of the pointer, Front size: 72 x 72 mm Input: 0-60 mV, DC Scale: 0-1.5 kA Accuracy class 1.5 with terminal cover

  • DF03-04

    TRANSDUCER:FREQUENCY,0 TO 20 MA DC OUTPU TRANSDUCER,FREQUENCY: OUTPUT RANGE: 0 TO 20 MA DC; STANDARD/SPECIFICATION: GOST 14014,BS 6253-1:1982, IEC 60688-1: 1980; ADDITIONAL DATA: FREQUENCY TRANSDUCER , DF03-04 , 0-20MA (PROGRAMMABLE)

  • DI125

    Transducer for AC (single phase)Input: A 5Scale factor: 1Frequency: 50 HzOutput: 4-20 mAAuxiliary voltage: 80 - 276V AC / DCAccuracy: Class 0.5according to IEC 688-2

  • DI125

    Transducer for AC (single phase), Input: 0-1 A Scale factor: 1 Frequency: 50 Hz Output: 4-20 mA Auxiliary voltage: 80 - 276V AC / DC Accuracy: Class 0.5 according to IEC 688-2

  • DP345

    ACTIVE POWER TRANSDUCER, PT. RATIO/NOMINAL VOLT: 11Kv/110 V CT. RATIO: 5000 A / 1 A FREQ.: 50 Hz

  • DPQ 345

    3 phase power transducer

  • DPT521-401

    Programmable transmitter

  • DPT-221(201)

    TRANSDUCER:POWER,4 TO 20 MA OUTPUT,48-26 TRANSDUCER,POWER: OUTPUT RANGE: 4 TO 20 MA; POWER SOURCE: 48 TO 260 VAC 50/60HZ/48 TO 368 VDC; STANDARD/SPECIFICATION: DIN 43807, IEC 688-1, IEC 60688; ADDITIONAL DATA: TRANSDUCER , 4-20MA (PROGRAMMABLE) MW M

  • DPT221- 401

    Programmable Transducer

  • DPT521- 401

    Programmable transmitter, Accuracy class 0.5, auxiliary voltage: 40-276 V AC / DC, 2 digital outputs, programmable 4 Analog outputs (20 mA), with RS485 Modbus Interface with USB interface parameterization
