Buschjost - 8590815.9678.02400
| Manufacturer | Buschjost |
|---|---|
| Part Number | 8590815.9678.02400 |
| Inner Code | 4036252 |
| Description | 2-way motor control valve |
| Custom Code | 84818059 |
| Technical specification | Type of proportional valve Control motor operated Connection G 1 Nominal width 20 mm Pressure range -0.9 - 16 bar kv value 4.40 m³ / h Temp. Medium -20 to + 90 ° C Temp. Environment -10 to + 40 ° C Voltage 24 V Frequency 00 Hz Protection type IP 54 Recording operation 3.3 W Duration 100% Installation preferably drive vertically upwards +/- 60 degrees Material housing brass Material seal NBR Switch funct. Throttle position with zero closure mech. Back pressure safe Seat tightness DIN EN 12266-1 Leak rate E. Additional information stepper motor, running time for 90 degree adjustment angle 10 to 11 s, integrated positioner, Setpoint specification 0-10V, 0-20 mA or 4 - 20 mA Analog output 0 - 20 mA / 4 - 20 mA State of delivery S1 = OFF, S2 = OFF: Setpoint specification 0-10 V. Analog output 0-20 mA electr. Connection via 5-pin M12 connector This product contains wear and tear share the depending on the use, subject to wear and tear. |
Please contact us to request a price quote for Buschjost - 8590815.9678.02400, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
