Buschjost - 8590140.8866.02400
| Manufacturer | Buschjost |
|---|---|
| Part Number | 8590140.8866.02400 |
| Inner Code | 4493644 |
| Description | valve top |
| Custom Code | 84818079 |
| Technical specification | Bellows valve type Control directly controlled Nominal size 8 mm Pressure range -0.9 - 0.9 bar Electr.exst. vent hole kV value 0.830 m³/h Temp medium +15 to +65°C Ambient temp +15 to +50°C voltage 24 V frequency 00 Hz Type of protection IP 65/connection IP 00 Suit 58 W Onset operation 3 W Inc. duration 22% playing time 1 sec installation as desired, preferably electrical magnet vertically upwards Wst.gasket PTFE Seat tightness DIN EN 12266-1 leak rate E Switching function closed in rest position mech. ex. valve without valve housing and without cover fixing screws wetted parts, oil and fat-free |
Please contact us to request a price quote for Buschjost - 8590140.8866.02400, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
