Buschjost - 8536300.6126.02400
| Manufacturer | Buschjost |
|---|---|
| Part Number | 8536300.6126.02400 |
| Inner Code | 4533775 |
| Description | 2/2-way solenoid valve |
| Custom Code | 84818079 |
| Technical specification | Series 85360 Designation 2/2-way solenoid valve Kind of piston valve Control indirectly controlled Connection G 3/4 Pressure level PN 40 Nominal width 20 mm Pressure range 0.5 - 40 bar kv value 7.00 m³/h Temp.Medium -20 to +80°C Ambient temp. -20 to +40°C Voltage 24V Frequency 00 Hz Explosion protection class II 2G Ex eb mb IIC T4 Gb II 2D Ex mb tb IIIB T125°C Db Protection type IP 66 EAC explosion protection 1Ex e mb IIC T4 Gb X Ex mb tb IIIB T125°C Db X electrical connection connection housing for cable 7-9 mm Cable entry M16 x 1.5 Recording operation 583 mA Lockup Duration 100% Any installation, preferably electric magnet pointing straight up Material housing brass Material seal NBR switching function closed at rest |
Please contact us to request a price quote for Buschjost - 8536300.6126.02400, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
