Buschjost - 8240200.9101.02400
| Manufacturer | Buschjost |
|---|---|
| Part Number | 8240200.9101.02400 |
| Inner Code | 171161 |
| Custom Code | 84818079 |
| Technical specification | series 82400 Designation 2/2-way solenoid valve Diaphragm valve Control indirectly controlled connection G 1/2 nominal width 12 mm Pressure range 0.1 - 16 bar Electr.extr. connector form A kV value 3.80 m³/h Temp. Medium 90°C Temp environment 50°C voltage 24 V frequency 00 Hz Protection type IP 65 Aufn.Suit 8 W Operation 8 W Inclusion duration 100% Any installation method, preferably electric magnet vertically upwards Wst. housing brass Wst. seal NBR Switching function closed in idle position Additional info Magnet with CSA test mark in accordance with C/US standards THERE IS CURRENTLY NO CSA APPROVAL BEFORE!!! The delivery includes product information attached. This product contains wear and tear share that depending on the application, are subject to wear and tear. |
| Weight | 1 |
Please contact us to request a price quote for Buschjost - 8240200.9101.02400, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
