Buschjost - G073.000384.042.099.040 / 3045D007
| Manufacturer | Buschjost |
|---|---|
| Part Number | G073.000384.042.099.040 / 3045D007 |
| Inner Code | 4927630 |
| Description | 3/2-way solenoid valve |
| Custom Code | 84818073 |
| Technical specification | for connection to 220V DC consists of: 073.000384 3/2 way solenoid valve (with 2/2-way blind plug - not included!) Article description: 3/045-23-0815-.352 Control type: directly controlled, differential pressure min. 0 bar Construction: spool valve Function: UN - universal version .: (Each port can be pressurized) Connection: 1/2" IG according to ISO 228/1 Seat: 10.0 mm Pressure: 0 - 250 bar Temperature (medium): -10°C/+80°C Temperature (ambient): -10°C/+35°C Viscosity (max): 22 mm²/s Material (housing): stainless steel 1.4571 Material (in contact with media): stainless steel 1.4571 Seal: FKM/PTFE, PEEK seat seal Installation: drive in a horizontal or upright position B0051.000445 with magnetic coil Type: .352 (K0513540) Voltage: 220 VDC Power: 150W Duty time: 100% ED Dust/water protection: IP65 Connection type: terminal box with M16x1.5 cable screw Cable clamp area: Ø5-10mm |
Please contact us to request a price quote for Buschjost - G073.000384.042.099.040 / 3045D007, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
