| Manufacturer | Burkert |
|---|---|
| Part Number | TYPE 0343 |
| Inner Code | 4289960 |
| Technical specification | PNEUMATIC VALVE |
Please contact us to request a price quote for Burkert - TYPE 0343, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
2/2-way solenoid valve; servo piston Type 5404 5404 Function A 2/2-way; Normally closed Nominal diameter 12.0 mm 12 Sealing material EB PTFE seat seal NBR + MS brass material GM84 line terminal G 1/2 sleeve Coil size 5 32 mm Voltage 024 volts 24 Frequency DC DC Power consumption 08 watts 8 Pressure range 1 - 50 bar Pressure max / gas 50 bar Weight: kg / pc 0.608
4/2-way pneumatic valve
4/2-way-pneumatic valve
2/2, G1 / 2 ", FKM, normal to, 24VDC, 0255 seri
3/2-way solenoid valve f. aggress. media Type 0124 0124 Action of T 3/2-way; Universal Einset 3/2-way; Universal used Nominal width of 03.0 mm 3 Seal material FKM FF Material PD PVDF (polyvinylidene fluoride) GM82 line terminal G 1/4 sleeve Voltage 024 volts 24 Frequency DC DC Power consumption 08 watts 8 Pressure range 0 - 4 bar
3WAY VALVE 220V
4/2-way pneumatic valve
pneumatic valve
3/2-way Rocker valve, 16mm analysis Type 6606 6606 Action of T 3/2-way; Universal Einset 3/2-way; Universal used Nominal size 1.6 mm 01,6 Seal material FFKM CC Material PD PVDF (polyvinylidene fluoride) DA20 line connection hose hose inner diameter 1.6 mm Coil size 0 Type Based specified Voltage 012 volts 12 Frequency DC DC Power AS 3.4 watts JC09 2 pressed FEP strands 0.2 mm ^ 2 AWG 24, white JW04 cable length 500 mm (19.5 inch) Pressure range -1 - 2 bar Pressure max / Gas 2 bar Weight: kg / pc 0.068
Type 0331 0331 Action of T 3/2-way; Universal Einset 3/2-way; Universal used Nominal diameter 02.0 mm 2 Seal material EPDM AA MS brass material Line connection FB02 flange: Bürkert KL-NR.001-01-18 (32x46) Voltage 024 volts 24
SERVO CONTROLLED MAGNETIC VALVE
Action of D 3/2-way; In the rest position the output B pressurized Nominal size 01,5 1,5 mm Seal material FKM FF MS brass material Line connection FB01 flange: Bürkert KL-NR.001-01-06 (32x32) Coil size 5 32 mm Voltage 230 230 Volt Frequency 50 50 Hz Power consumption 08 watts 8 Pressure range 0 - 16 bar Pressure max / gas 16 bar
2/2-way solenoid valve
2/2-way control piston diaphragm valve Type 2030 2030 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 15.0 mm 15 Sealing material AB EPDM (Food Grade) Material PVC PV Line connection KM25 adhesive connection sleeve diameter 20mm Drive Version C PA Drive, VA-threaded socket on the Control air connection Actuator size D DM 50 mm Pressure range 0 - 8.5 bar
2/2-way control piston diaphragm valveType 2031 2031Control function A closed with spring forcePaths / positions 2 2 way / 2-positionNominal diameter 25.0 mm 25Sealing material AB EPDM (Food Grade)Material Stainless steel VAGM86 line connection socket G 1Drive Version C PA Drive, VA-threaded socket on theControl air connectionActuator size F DM 80 mmoutside NO01 glass bead blasted Ra 1.6 microns / Ra64 microinchesNo05 inner glass bead blasted Ra 1.6 microns / Ra64 microinchesPressure range 0 - 10 bar
2/2-way valve with isolating diaphragm for medium up to +100ºC
5/2-way pneumatic valve 10 mm
2/2, G1 / 2 ", brass, NBR, 24VDC, 0256 seri
3/2-way solenoid valve, direct-acting
3/2-way solenoid valve f. aggress. media Type 0121 0121 Mode of action F 3/2-way; distribution valve Nominal width of 6 mm 06,0 Seal material FKM FF Material PD PVDF (polyvinylidene fluoride) GM83 line terminal G 3/8 sleeve Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power CE 60 Watt suit, 3 watt operation Special CZ05 Internal High Performance JC01 pressed-in tubular cables HO5RN-F3GO, 7 JW10 cable length 3000 mm Pressure range 0 - 2 bar Weight: kg / pc 0.320
solenoid valves
manometer which is part
2/2 way solenoid valve ½ PN1-40 BAR 230V 50-60 HZ 8W
2/2-way solenoid valve; servo piston Type 5404 5404 Action of B 2/2-way; Normally open Nominal diameter 12.0 mm 12 Sealing material EB PTFE seat seal NBR + MS brass material GM84 line terminal G 1/2 sleeve Coil size 5 32 mm Voltage 230 230 Volt Frequency 56 Hz 50-60 Power consumption 08 watts 8 CF05 special coil or plugs with vent G1 / 8 DE85 core 0311-1015-260-00 Pressure range 1 - 40 bar Weight: kg / pc 0.595
3/2-way solenoid valve
2/2-way solenoid valve; servo-controlled Type 5281 5281 Generation 00 Unspecified Function A 2/2-way; Normally closed Nominal diameter 50.0 mm 50 Seal material NBR BB MS brass material GM89 line connection sleeve 2 G Coil size 6 40 mm Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power consumption 09 watts 9 Special JA01 Terminal box with cable gland M20 x 1.5 (With approval PTB 00 ATEX 3119 X) + fuse (With approval PTB 01 ATEX 2064) MA02 Electrical connection via valve outlet MB05 cable outlet upwards PD53 Zulas. PTB 00 ATEX 2129X Ex m II T4 (without Kl. box) Ex em II T4 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max. Surface temperature of 135 ° C, 9 W (only Individual installation) Pressure range 0,2 - 10 bar
More directional spool valve Type 0450 0450 Function H 5/2-way; In the rest position output 2 pressurized Nominal diameter 14.0 mm 14 GM84 line terminal G 1/2 sleeve Electromagnetic actuating EL. 32x32, air suspension Voltage 024 volts 24 Frequency UC direct and alternating current (AC / DC) JW12 cable length 5000 mm MW17 Vorsteurung Type 6014 PD49 Zulas. PTB 00 ATEX 2129 X Ex m II T5 (without Kl. Box), Ex em II T5 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max Surface temperature of 100 ° C, 3 W (only Individual installation) Pressure range 1 - 10 bar Weight kg / St 1,599
