Burkert - Typ 0330 / Article number 20036977
| Manufacturer | Burkert |
|---|---|
| Part Number | Typ 0330 / Article number 20036977 |
| Inner Code | 4846682 |
| Description | 3/2-way solenoid valve; direct-acting |
| Custom Code | 84818079 |
| Technical specification | Type 0330 3/2-way operation; output A relieves load in rest position Nominal diameter 3 mm FKM sealing material PVDF material industry standard G 1/4 socket cable connection Voltage 24 volts DC frequency Power consumption 5 watts specificity Analytical version + vacuum version in accordance with FST DIS 1000020797 (WN 06 3 50054) UL Recognized coil for USA and Canada cURus UL File MH19303 Pressure (bar) (min) -1 Pressure (bar) (max) 4 Medium temperature (degrees C) (max) 80 Ambient temperature (degrees C) (max) 55 KV value (M*3/H) 0.25 QNN value (L/MIN) 270 Duty time (%) 100 Opening time (ms) (min) 10 Opening time (msec) (max) 20 TOTYPE 10 Closing time (ms) (min) 20 |
Please contact us to request a price quote for Burkert - Typ 0330 / Article number 20036977, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
