| Manufacturer | Burkert |
|---|---|
| Part Number | 00463587 |
| Inner Code | 4264502 |
| Description | 2/2-way angle globe valve |
Please contact us to request a price quote for Burkert - 00463587, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
2/2-way angle globe valve
Type AC10 AC10 Interface. Valve / coil U3 Zentralverschraubt, core diameter 10.6 mm, universal Coil size 5 32 mm Coil winding 19ab
024/DC/04 Typ AC07 AC07 U2 CENTRAL SCREW, CORE DIAMETER 7 MM UNIVERSAL 20 MM 21AA
Mode of operation H 5/2-way; At rest, output 2 pressurized Nominal width 04,0 4 mm Cable connection 1 FM14 flange pattern type 6525 Line connection 2 0000 not available Operating mode Z electropneumatic based on type 6144 Set spool size 0 type-specific voltage 024 24 volts Frequency BA battery power Power consumption AA 0.8 Watt JB17 Right PIN positive pole JF80 Rectangular Plug Connector 5.08 mm, 2 Pin Pressure range 2.5 - 10 bar Weight: kg/st 0.025
Mode of operation H 5/2-way; At rest, output 2 pressurized Nominal width 04,0 4 mm Cable connection 1 FM14 flange pattern type 6525 Line connection 2 0000 not available Operating mode Z electropneumatic based on type 6144 Set spool size 0 type-specific voltage 024 24 volts Frequency BA battery power Power consumption AA 0.8 Watt JB17 Right PIN positive pole JF80 Rectangular Plug Connector 5.08 mm, 2 Pin Pressure range 2.5 - 10 bar
2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 15.0 mm 15 Seal material PTFE EE Material RG gunmetal GM84 line terminal G 1/2 sleeve Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size D DM 50 mm AF12 Short housing MC13 flow direction above seat MS74 mounted V-ANTR Pressure range 0 - 16 bar Weight: kg / pc 0.732
5/2-way pneumatic valve
2/2-way solenoid valve; servo-controlled Type 5282 5282 Generation 00 Unspecified Action of B 2/2-way; Normally open Nominal diameter 13.0 mm 13 Sealing material BB NBR; Material MS brass; line connection GM84 G 1/2 sleeve; coil size set 0 Type Relative; Voltage 230 230 V; frequency 56 50-60 Hz; power 08 8 watts; special MT50 feedforward WWC or WWD; Pressure Range 0.2 - 16 bar, weight: kg / St 0.920
(2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 20.0 mm 20 Seal material NBR BB Material RG gunmetal GM85 line connection G 3/4 sleeve Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size D DM 50 mm AF12 Short housing MC13 flow direction above seat Pressure range 0 - 16 bar Weight: kg / pc 0.940 Substitution for Id.-Nr. 166257)
Follow-up to 166257 1: 1 2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 20.0 mm 20 Seal material NBR BB Material RG gunmetal GM85 line connection G 3/4 sleeve Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size D DM 50 mm Special AF12 Short housing MC13 flow direction above seat Pressure range 0 - 16 bar Weight: kg / pc 0.940
VALVE:SOLENOID,3/4 IN PIPE,DN 13 ORIFICE VALVE,SOLENOID: PIPE SIZE: 3/4 IN; ORIFICE DIAMETER: DN 13; ELECTRICAL RATING: 24 VDC, 60 HZ, 9 W; CONFIGURATION: 2 WAY; CONNECTION: THREADED (TUBE NOZZLE); OPERATION: ELECTRIC; PRESSURE RATING: 0 TO 16 BAR; ENCLOSURE: IP 65; BODY MATERIAL: BRASS; ADDITIONAL DATA: USED FOR WASHING WATER SYSTEM, WESTFALI A OIL SEPERATOR.
solenoid valve(0330 A 3.0 FKM G1/4)
5/2 W SOLENOID VALVE
(Pneumatic function D3 double and single acting QNn = 100 l / min Proximity switch 00 Without Flange FA06 interface SideControl 879x Namur flange Supply voltage E 24V DC F control 0-10V, 0-5V, 4-20mA, 0-20mA set Electr. Connection KD grommet Fluid connection G 1/4 GI Operation / Config. T keyboard and display internally Inputs / outputs F 1 binary + 1 analog output + 2 Binary Without additional function 0 Communication 0 Without PK02 usCSAc approved control)
Digital electro-pneumatic positioner: Positioner SideControlc
SIDE CONTROL POSITIONER PARALLEL ACTING
a-1.6 3bar 12 volt,2-way valve
(Type 2 0400 0400 Action of B 2/2-way; Normally open nominal diameter 12.0 mm 12 Seal material NBR BB Material 00 without housing or not specified Coil size 0 Type Based specified Current Type E DC Power consumption 00 without coil ID number 00214398 Special Z303)
Valve island 24 times 8644 6524 Type 8644 8644 Pitch 11 11 mm Num. mono rod. 3/2 valves 24 24 valves Num. monostab.4 + 5/2-valve 00 No Number Bistab. 5/2 valves 00 No Number Bistab. 5/3 valves 00 No Num. not bel. Ventilpl. 00 No Electr. Control 000 without electric. control Manufacturer Siemens SI Number of digital inputs 00 No Input Number of analog inputs 00 no Number of digital outputs 00 No Output Number Analog Outputs00 no Line connection 1 GM82 G 1/4 sleeve Cable Connection 2 TA22 hose connector tubing diameters 6mm Approval 00 NO Protection IP20 20 Pneumatic pressure gauge 1 with pressure gauge Pneumat. 1 particularity with non-return valves Pneumat. Special X 2 x contain 3/2-way, Ve 1 Electr. Special 0 None Accessories 0 Without Weight: kg / pc 1.618
forced control (2/2-way solenoid valve, Type 6213 6213 generation EV Function A 2/2-way; Normally closed Nominal diameter 13.0 mm 13 Seal material NBR BB MS brass material GM84 line terminal G 1/2 sleeve Coil size 6 40 mm Voltage 024 volts 24 Frequency DC DC Power 10 10 Watts Pressure range 0 - 10 bar Weight: kg / St0,535)
2/2-way-solenoid valve, servo coupled
valve
Succession device or new item number: positively controlled 2/2-way solenoid valve, Type 6213 6213 generation EV Function A 2/2-way; Normally closed Nominal diameter 10.0 mm 10 Seal material NBR BB MS brass material GM82 line terminal G 1/4 sleeve Coil size 6 40 mm Voltage 024 volts 24 Frequency DC DC Power 10 10 Watts Pressure range 0 - 10 bar Weight: kg / pc 0.444
positively controlled 2/2-way solenoid valve, type 6213
2/2-way solenoid valve; servo-controlled
(Generation EV Function A 2/2-way; Normally closed nominal diameter 13.0 mm 13 Seal material NBR BB MS brass material GM84 line terminal G 1/2 sleeve Coil size 5 32 mm Voltage 230 230 Volt Frequency 56 Hz 50-60 Power consumption 08 watts 8 Pressure range 0,2 - 16 bar Weight: kg / pc 0.521)
2/2-way solenoid valve; servo-controlled Type 6281 6281 generation EV Action of B 2/2-way; Normally open Nominal diameter 13.0 mm 13 Seal material NBR BB MS brass material GM84 line terminal G 1/2 sleeve Coil size 5 32 mm Voltage 024 volts 24 Frequency DC DC Power consumption 08 watts 8 Special NA38 coil for higher temperatures Pressure range 0,2 - 16 bar Weight: kg / pc 0,550
3/2-way solenoid valve; direct acting
2/2-way solenoid valve; servo-controlled Type 0290 0290 Function A 2/2-way; Normally closed Nominal diameter 12.0 mm 12 Seal material FKM FF MS brass material GM84 line terminal G 1/2 sleeve Voltage 230 230 Volt Frequency 50 50 Hz Power 10 10 Watts Special JF01 standard cable head MA02 Electrical connection via valve outlet MT05 Direct coupling NL02 suitable for applications with oxygen (Non-metallic wetted materials are BAM-tested), Blue Label, DIS 1000020797 Pressure range 0 - 16 bar
