Burkert - P/N: 00184310, Type: 6511-H02,5-FM09-0000-Z0-024/BA-AA * HA01+JB17+JF80
| Manufacturer | Burkert |
|---|---|
| Part Number | P/N: 00184310, Type: 6511-H02,5-FM09-0000-Z0-024/BA-AA * HA01+JB17+JF80 |
| Inner Code | 2298 |
| Description | 5/2-way pneumatic valve |
| Custom Code | 84812090 |
| Technical specification | Type - 6511 - 6511 Mode of operation - H - 5/2 ways; at rest outlet 2 pressurized Nominal diameter - 02.5 - 2.5 mm Line connection 1 - FM09 - flange pattern interface module/valve for type 6511 Line connection 2 - 0000 - not available Type of actuation - Z - electropneumatic based on electropneumatic based on type 6144 Spool size - 0 - determined by type Voltage - 024 - 24 Volt Frequency - BA - battery current Power consumption - AA - 0.8 watts Special feature: HA01 - Without manual operation JB17 - Right PIN positive pole JF80 - 5.08 mm 2-pin rectangular plug connector Pressure min - 2.50 bar Pressure max - 7 bar QNN - 150 l/min Medium temp. min - (-10) °C Medium temperature max - 50 °C Ambient temp. min - (-10) °C Ambient temperature max - 55 °C |
| Weight | 0.022 |
Please contact us to request a price quote for Burkert - P/N: 00184310, Type: 6511-H02,5-FM09-0000-Z0-024/BA-AA * HA01+JB17+JF80, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
