Bifold - XS08-08-AF4PS2-77G-24D-30-AL-10X3-X8
| Manufacturer | Bifold |
|---|---|
| Part Number | XS08-08-AF4PS2-77G-24D-30-AL-10X3-X8 |
| Inner Code | 4585304 |
| Description | 3/2 way manifold control unit |
| Custom Code | 8481209090 |
| Technical specification | Item no [13732] 1/2" NPT - Manifold - XS08-08 Mtr.: Bifold fluid power Type: XS08-08-AF4PS2-77G-24D-30-AL-10X3-X8 Material:SS316L Operating temperature range: -60°C to +40°C (@T6) XS08-08 Manifold control unit 1/2", 1/2" NPT connection A 2-way ball valve F4 filter regulator (manual drain) with pressure gauge P 3/2-way SPR pneumatic valve (with pilot line stack capabilities), NC S2 FP03P - 3/2 way solenoid valve with manual override (M), . NC, direct acting 77G degree of protection: Cu-TR/IECEx, Ex d IIC Gb, Ex tb IIIC db T4/5/6 24D power supply 24V DC 30 Power consumption 3.0 watts AL seals Flourosilicone (-60°C to +90°C) 10X3 outlet pressure range 0.4 - 10 bar, filter element 20 - 30 μm X8 pressure gauge Ø50mm, 0-10bar, 1/8" NPT connection, glycerine filled gauge No exhaust flow control, exhaust breathers |
Please contact us to request a price quote for Bifold - XS08-08-AF4PS2-77G-24D-30-AL-10X3-X8, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
