Berthold - 50036-120
| Manufacturer | Berthold |
|---|---|
| Part Number | 50036-120 |
| Inner Code | 513415 |
| Technical specification | Uni-Probe LB 490-91 Level Gauge signal output: FieldbusFoundation scintillator: NaI 50/50 collimator with frontal irradiation power supply 95-250VAC automatic drift compensation automatic decay compensation internal self monitoring ambient temp: -40°C to +50°C - 1 analog output: 0/4 - 20 mA, isolated signal output switchable between FF-Bus and HART - 1 digital-Input for hold-signal - 3 relays, alternative signals: hold, max / min alarm, detector temp., rad. interference - 1 failure relay relays: Max. 250VAC or 30VDC at max. 5A non-inductive 4 conduits radial, 3/4" NPT flame proof protection ATEX: II 2 GD EEx d IIC T6 IP66 T 70°C flame proof protection FM/CSA: Class I, Division 1&2, Groups A, B, C, D Class II, Division 1&2, Groups E, F, G protection: Nema 4X / IP 66 housing: stainless steel Customs tariff number: 90222900 |
| Weight | 1 |
Please contact us to request a price quote for Berthold - 50036-120 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
