Berthold - 47678-130
| Manufacturer | Berthold |
|---|---|
| Part Number | 47678-130 |
| Inner Code | 513394 |
| Technical specification | Uni-Probe LB 490-11 Level Evaluation Unit Plastic scintillator length 500mm Power supply 95-230V Menu controlled calibration via HART-communicator Automatic decay compensation Self monitoring Ambient temp: -20 to +50 - 1 analog output: 0/4 - 20 mA, isolated - 1 digital-Input for hold-signal Relays: Max. 250VAC or 30VDC at max. 5A noninductive - 3 relays, alternative signals: hold, max / min alarm, detector temp., rad. interference - 1 failure relay 4 conduits radial 3/4" NPT Flame proof protection: ATEX: II 2(1)GD Ex d [ia] IIC T6 IP66 T 80°C Intrinsically safe current output in sink mode, with 20m cable, pre-assembled Protection: Nema 4X / IP 66 Housing: stainless steel Customs tariff number: 90222900 |
| Weight | 1 |
Please contact us to request a price quote for Berthold - 47678-130 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
