Bernstein - Art.No.6613299079 Type: C74-ANALOG 4-20mA B
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6613299079 Type: C74-ANALOG 4-20mA B |
| Inner Code | 663397 |
| Description | Analogue block |
| Technical specification | Electrical Data Rated operating voltage range UB 12 - 26 V DC Idle current Io < 25 mA Short-circuit protection type synchronising, permanently short-circuit and overload protected Reverse polarity yes Readiness delay tv < 50 ms Analogue output Current output 4 – 20 mA Linearity errors ≤± 2,5 % from the end value (20 mA), UB and temperature at a constant level Temperature errors ≤± 10 % UB constant level Repetition accuracy R ≤ 2 % from the end value (20 mA), UB and temperature at a constant level max. load resistor RB 400 Ω Switching output switching element function S PNP NO (teachable) Hysteresis H ≈ 10 % Voltage drop Ud ≤ 1,6 V Utilization category DC 12 Rated operational currents Ie 200 mA Minimum operating current Im 1 mA Residual current Ir < 0,1 mA Switching frequency max. 100/min. |
| Weight | 1 |
Please contact us to request a price quote for Bernstein - Art.No.6613299079 Type: C74-ANALOG 4-20mA B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
