Bernstein - Art.No.6613299076 Type: C74-ANALOG 0-5V B
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6613299076 Type: C74-ANALOG 0-5V B |
| Inner Code | 663394 |
| Description | Analogue block |
| Technical specification | Electrical Data Rated operating voltage range UB 12 - 26 V DC Idle current Io < 25 mA Short-circuit protection type synchronising, permanently short-circuit and overload protected Reverse polarity yes Readiness delay tv < 50 ms Analogue output Voltage output 0 – 5 V Linearity errors max. ± 2,5 % from the end value (5 V), UB and temperature at a constant level Temperature errors max. ± 10 % UB constant level Repetition accuracy R ≤ 2 % from the end value (5 V), UB and temperature at a constant level min. Load resistance RL2 750 Ω Switching output switching element function S PNP NO (teachable) Hysteresis H ≈ 10 % Voltage drop Ud ≤ 1,6 V Utilization category DC 12 Rated operational currents Ie 200 mA Minimum operating current Im 1 mA Residual current Ir < 0,1 mA Switching frequency max. 100/min. |
| Weight | 1 |
Please contact us to request a price quote for Bernstein - Art.No.6613299076 Type: C74-ANALOG 0-5V B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
