Bernstein - Art.No.6507907004 Type: KCB-M30PS/010-KLPS12 A
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6507907004 Type: KCB-M30PS/010-KLPS12 A |
| Inner Code | 663269 |
| Description | Capacitive Proximity Switch |
| Technical specification | Electrical data Rated operating distance Sn 10 mm Mounting flush Standard target 30 x 30 x 1 mm; material: steel; connected to earth Effective operating distance Sr 2-10 mm; Sr adjustable with potentiometer (POT); turn right ≙ high sensitivity, turn left ≙ low sensitivity Assured operating distance Sa 0 ≤ Sa ≤ 0,8∙Sr Switching element function N.O. Repeat accuracy R ≤ 0,1∙Sr Differential travel (hysteresis) H ≤ 0,2∙Sr Frequency of operating cycles f ≈ 25 Hz Rate doperational voltage Ue 12 V - 48 V DC Operational voltage range UB 10 V - 60 V DC Rated insulation voltage Ui 75 V DC Rated impulse withstand voltage Uimp 500 V Voltage drop Ud ≤ 3 V DC Utilization category DC-13 (Switching element) Rated operational current le 400 mA DC Minimum operational current Im 1 mA DC Off–state current lr ≤ 0,5 mA DC No–load supply current lo ≤ 20 mA DC Switching element permanent overload and s.c.p. Short–circuit protection pulsed False polarity protection with permutation of +, –, output no damage occurs |
| Weight | 1 |
