Bernstein - Art.No.6503503001 Type: KIB-M12AS/002-L2 C
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6503503001 Type: KIB-M12AS/002-L2 C |
| Inner Code | 663221 |
| Description | Inductive Proximity Switch |
| Technical specification | Electrical data Rated operating distance Sn 2 mm Standard target 8 mm x 8 mm, t = 1mm; material: FE360 Mounting flush Assured operating distance Sa 0 … 1,6 mm Switching element function AC, N.O. Repeat accuracy R ≤ 5 % Differential travel (hysteresis) H ≤ 0,2 x Sr Rated operational voltage Ue 230 V AC Operational voltage range UB 76 – 250 V AC Rated insulation voltage Ui 250 V Voltage drop Ud ≤ 10 V AC (r.m.s.) Utilization category AC 140 Rated operational current le 200 mA Minimum operational current Im ≤ 5 mA Off–state current lr < 2,5 mA Short-time current 1 A, 1 half-wave Short–circuit protection without Frequency of operating cycles f ≈ 10 Hz Rated supply frequency 50 Hz, 60 Hz Protection class I I Time delay before availability tv ≤ 100 ms Electromagnetic compatibility (EMC) Electromagnetic field test IEC 61000-4-3 Electrostatic discharge test IEC 61000-4-2 Electrical fast transient immunity test IEC 61000-4-4 Radiated disturbance field strength CISPR11 |
| Weight | 1 |
Please contact us to request a price quote for Bernstein - Art.No.6503503001 Type: KIB-M12AS/002-L2 C, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
