Bernstein - Art.No.6502903016 Type: KIB-M12PS/002-KL2V C
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6502903016 Type: KIB-M12PS/002-KL2V C |
| Inner Code | 663109 |
| Description | Inductive Proximity Switch |
| Technical specification | Series M12 Electrical data Rated operating distance Sn 2 mm Standard target 12 mm x 12 mm, t = 1 mm, Material: FE360 Effective operating distance Sr 1,8 ... 2,2 mm Assured operating distance Sa 0 ... 1,6 mm Switching element function DC, N.O. Repeat accuracy R ≤ 5 % Differential travel (hysteresis) H 10 % Rated operational voltage Ue 12 – 24 V DC Operational voltage range UB 10 – 36 V DC Rated insulation voltage Ui 75 V DC Rated impulse withstand voltage Uimp 500 V Voltage drop Ud ≤ 1,5 V Utilization category DC 13 Rated operational current le ≤ 200 mA Minimum operational current Im ≤ 1 mA Off–state current lr < 0,1 mA No–load supply current lo ≤ 11 mA Switching element Permanent overload and s.c.p. Short–circuit protection pulsed Frequency of operating cycles f 800 Hz Rated supply frequency DC Mounting flush False polarity protection yes Time delay before availability tv ≤ 50 ms Electromagnetic compatibility (EMC) Electromagnetic field test IEC 61000-4-3 Electrostatic discharge test IEC 61000-4-2 Electrical fast transient immunity test (Burst) IEC 61000-4-4 Radiated disturbance field strength EN 55011 |
| Weight | 1 |
Please contact us to request a price quote for Bernstein - Art.No.6502903016 Type: KIB-M12PS/002-KL2V C, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
