Bernstein - Art.No.6411211384 Type: MAK-1112-B-5 B
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6411211384 Type: MAK-1112-B-5 B |
| Inner Code | 662951 |
| Description | Magnetic switch |
| Technical specification | Assured operating distance Sa 10 mm Switching element function Make function Max. switching voltage 250 V Max. switching current 0,5 A Max. switching capacity 10 VA Mechanical lifetime 3 x 108 switchings, however, according to load resetability Repeat accuracy R ± 0,1 mm under same geometrical conditions at the same temperature Max. Release point 22 mm Shock 50 g (11 ms / ½ Sinewave) Vibration 35 g (10 - 1000 Hz) Enclosure PA 6.6; encapsulated reed contact Ambient air temperature -5 °C ... +70 °C Type of protection IP67 acc. ICE 529, EN 60529 Termination type cable 2 x 0,14 mm2 ; PVC -outer jacket black Assembly position optional (assembly on iron means reduction of switch distance) |
| Weight | 1 |
Please contact us to request a price quote for Bernstein - Art.No.6411211384 Type: MAK-1112-B-5 B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
