Bernstein - Art.No.6410412143 Type: MAK-1214-L-2 C
| Manufacturer | Bernstein |
|---|---|
| Part Number | Art.No.6410412143 Type: MAK-1214-L-2 C |
| Inner Code | 662944 |
| Description | Magnetic Switch |
| Technical specification | Series MA-12 Output function bistable Max. switching voltage 250 V DC Max. switching current 1,0 A Max. switching capacity 60 VA Min. switching capacity 3 VA Mechanical lifetime 3 x 108 switchings, however, according to the load resetability Repeat accuracy R ± 0,1 mm, under same geometrical conditions at the same temperature Enclosure PA6.6, red; encapsulated reed contact Ambient air temperature -5 °C … +70 °C Type of protection IP 67 acc. to EN 60529 Termination type Cable 2 x 0,5 mm² x 2 m; PVC – Outer jacket, black Assembly position optional (assembly on iron means reduction of switch distance) |
| Weight | 1 |
Please contact us to request a price quote for Bernstein - Art.No.6410412143 Type: MAK-1214-L-2 C, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
