Bd Sensors - DMP 334 / 140-7003-E-3-100-200-2-000
| Manufacturer | Bd Sensors |
|---|---|
| Part Number | DMP 334 / 140-7003-E-3-100-200-2-000 |
| Inner Code | 4885156 |
| Description | pressure transducer |
| Custom Code | 90262020 |
| Technical specification | Device type: DX19-DMP 334 Measurement variable: relative Code input: 0... 700 bar Electrical output: 4... 20 mA/2-wire Ex-version 1: II 1G Ex ia IIC T4 Ga Ex-version Zone 20: II 1D Ex ia IIIC T135 °C Da IEC: IECEx IBE 12.0027X ATEX: IBExU10ATEX1068X Pi: 660 mW Ui: 28 V Ii: 93mA Ci: #0 nF CGND: 27 nF Li: approx. 0 µH CE number: 0637 Type plate: BDS GmbH Supply: 14... 28 VDC Accuracy: 0.35% FSO IEC Protection class: IP65 supply +: 1 Supply -: 2 Screen: Grounding Mechanical connection: G1/2" EN 837 Seal: without (welded version) Special version: Standard nameplate - Position: Standard Electrical connection: ISO 4400 plug and cable socket Name: Please note safety-relevant data the Ex-version in the data sheet, user manual and type examination certificate |
Please contact us to request a price quote for Bd Sensors - DMP 334 / 140-7003-E-3-100-200-2-000, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
