Bd Sensors - DMP 333 / 130 4003 E 3 100 200 1 000
| Manufacturer | Bd Sensors |
|---|---|
| Part Number | DMP 333 / 130 4003 E 3 100 200 1 000 |
| Inner Code | 4830741 |
| Description | pressure transducer |
| Custom Code | 90262020 |
| Technical specification | Device type: DX19-DMP 333 Measurement variable: relative Code input: 0... 400 bar Electrical output: 4... 20 mA/2-wire, Ex ia Supply: 10... 28 VDC Accuracy: 0.35% FSO IEC Supply +: 1 Supply -: 2 Screen: Grounding Protection class: IP65 Mechanical connection: G1/2" EN 837 Seal: FKM Special version: ATEX standard: IBExu10ATEX1068 X Ex-version: II 1G Ex ia IIC T4 Ga Ex-version Zone 20: II 1D Ex ia IIIC T135°C Da UI: 28 VDC II: 93 mA Pi: 660 mW Ci: 0 nF Li: 0 µH C GND: 27 nF CE number: 0637 IEC: IECEx IBE 12.0027X Ex-version (IEC): Ex ia IIC T4 Ga Ex-version Zone 20 (IEC): Ex ia IIIC T85 °C Da Type plate: BDS GmbH Type plate - Position: Standard Electrical connection: ISO 4400 plug and cable socket |
Please contact us to request a price quote for Bd Sensors - DMP 333 / 130 4003 E 3 100 200 1 000, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
