Bd Sensors - DMP 331 / 110-4002-E-3-100-200-1-000
| Manufacturer | Bd Sensors |
|---|---|
| Part Number | DMP 331 / 110-4002-E-3-100-200-1-000 |
| Inner Code | 4885152 |
| Description | pressure transducer |
| Technical specification | Device type: DX19-DMP 331 Measurement variable: relative Code input: 0... 40 bar supply: 10... 28 VDC Accuracy: 0.35% FSO IEC supply +: 1 Supply -: 2 Screen: Grounding Protection class: IP65 Mechanical connection: G1/2" EN 837 Seal: FKM Special version: Standard ATEX: IBEXU10ATEX1068 X Ex-Version: II 1G Ex ia IIC T4 Ga Ex-version Zone 20: II 1D Ex ia IIIC T135°C Da Ui: 28 VDC Ii: 93mA Pi: 660mW Ci: 0 nF Li: 0 µH C GND: 27 nF Number CE: 0637 IEC: IECEx IBE 12.0027X Ex-version (IEC): Ex ia IIC T4 Ga Ex-version zone 20 (IEC): Ex ia IIIC T85 °C There is a type plate: BDS GmbH Type plate - position: standard Electrical output: 4... 20 mA/2-wire with explosion protection (Ex ia) Electrical connection: ISO 4400 plug and cable socket Name: Please note safety-relevant data the Ex-version in the data sheet, user manual and type examination certificate |
Please contact us to request a price quote for Bd Sensors - DMP 331 / 110-4002-E-3-100-200-1-000, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
