Banner Engineering - T86EVQ5
| Manufacturer | Banner Engineering |
|---|---|
| Part Number | T86EVQ5 |
| Inner Code | 795063 |
| Description | SELF-CONTAINED BARREL-MOUNT SENSOR |
| Technical specification | Part Number: 70687 Sensing Beam Visible Red LED Power DC Sensing Mode (General) Opposed Sensing Mode (Detailed) Emitter Housing Style Barrel Primary Housing Material Thermoplastic Max Sensing Distance (mm) 2000 Power Supply/Supply Voltage 10-30 V dc Connection Pigtail QD Quick Disconnect Type M12 Operation N/A Min Op. Temp. (°C) -20 Max Op. Temp. (°C) 55 Output response time (ms) 1 ON/0.5 OFF Special Feature: Intrinsically Safe No Special Feature: Remote Teach No Special Feature: Water Detection No Delay at Power-up (ms) 100 Repeatability (µs) 100 Number of Pins 4 NEMA Rating NEMA 6 IP Rating IP67 Max Op. Relative Humidity [%] 90% @ 50°C Lens Material Acrylic Adjustments N/A Barrel Diameter (mm) 8 Indicator LEDs Opposed Mode Emitter/Receiver Emitter Feature: Timing (Hold/Delay) No Feature: Encapsulated No Feature: Hazardous Area No Feature: Audible No Feature: Chemical Resistant No Feature: Quick Disconnect Yes DeviceNet No IO Link No |
| Weight | 1 |
Please contact us to request a price quote for Banner Engineering - T86EVQ5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
