Banner Engineering - K30LMXXPPB2
| Manufacturer | Banner Engineering |
|---|---|
| Part Number | K30LMXXPPB2 |
| Inner Code | 795098 |
| Description | GENERAL PURPOSE ILLUMINATED PUSH BUTTONS |
| Technical specification | Power DC Display No Housing Style Base Mount - Dome Window Primary Housing Material Polycarbonate Actuation Yes Activation Function Push-Button Mounting Thread M22 x 1.5 Color Input Control Individual (One wire/color, same number of colors as input wires) Number of Colors 1 Product Size (mm) 30 Color Technology Standard LED Color Option 1 Magenta Animation Option 1 Solid On Connection Cable Max Current Color (mA) 40 Number of Input Pins/Conductors 4 Operation Normally Open Supply Voltage 10-30 V dc Output Type Dry Contact Input Type PNP Max Input Response Time (ms) 1 Max Output Response Time (ms) 10 Physical Dimensions (LxWxH or DxH mm) 30.0 x 49.4 Environmental Rating IP67 NEMA Type and UL Type Rating NEMA 13 Max Op. Temperature (°C) 50 Min Op. Temperature (°C) -40 Storage Temp (°C) -40 to 70 Primary Housing Color Black Button Operation Momentary Primary Window Material Polycarbonate Diffused Secondary Material Thermoplastic Feature: Hazardous Area No Feature: Audible No Feature: Chemical Resistant No Multi-Color Device Single Color On Feature: Quick Disconnect No IO Link No Modbus RTU No Wireless No Pro-Editor Compatible (Discrete) No |
| Weight | 1 |
Please contact us to request a price quote for Banner Engineering - K30LMXXPPB2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
