Balluff - BAW M18MI-UAC50B-S04G / BAW002K
| Manufacturer | Balluff |
|---|---|
| Part Number | BAW M18MI-UAC50B-S04G / BAW002K |
| Inner Code | 201986 |
| Custom Code | 85365019 |
| Technical specification | Analog sensor BAW M18MI-UAC50B-S04G, Statistical Item Number 85365019, 278053 (MTS). Dimensions = Ø 18 x 65 mm | Design = M18x1 | Installation = flush | Range = 1... 5 mm | Analog output = analog, voltage 0... 10 V | Output characteristic = falling when approaching | Limit frequency —3 dB = 500 Hz | Repeatability according to BWN = ±8 μm | Linearity deviation max. = ±120 μm | Housing material = brass, nickel-plated | Active surface, material = PBT | Connection = Connector, M12x1 plug, 3-pin | Operating voltage Ub = 15... 30 VDC | Ambient temperature = -10... 70 °C | Protection class = IP67 | Approval/Compliance = CE, UKCA, cULus, WEEE |
| Weight | 1 |
Please contact us to request a price quote for Balluff - BAW M18MI-UAC50B-S04G / BAW002K, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
