Bailey & Mackey - Type 2381

Manufacturer Bailey & Mackey
Part Number Type 2381
Inner Code 584639
Description Twin Circuit Pressure Switch
Technical specification Range: 0.2 to 4 bar Process Connection: 50mm BS EN 1092 PN16 Raised face flange Wetted parts: 316 Stainless Steel connection with a 316 Stainless Steel diaphragm protection disc Seal: PTFE Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac CE marked With 6 x push on crimp connectors
Weight 1

Please contact us to request a price quote for Bailey & Mackey - Type 2381 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Bailey & Mackey-Type 2381 price

More products of Bailey & Mackey

  • Type 1382

    Differential Pressure Switch

  • 1392P

    Pressure Switch

  • TYPE 14

    Pressure Switch Range: 0.4 to 4 bar Process Connection: 1/8” BSP male, taper Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile SPDT microswitch

  • TYPE 2381P

    Twin Circuit Pressure Switch Range: 2 – 28 bar Process Connection: ¾ ”NPT male Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile Electrical Entry: 7-pin plug & socket Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac C/W push on crimp connectors CE marked

  • TYPE 2382 / 0484792003

    (Type 2382 Twin Circuit Differential Pressure Switch Range: 0.07 – 1 bar Process Connection: 1/4” BSP female, parallel Wetted parts: brass chambers with a beryllium copper diaphragm Seal: Nitrile Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac Max line pressure 34 bar C/W wall mounting bracket and push on crimp connectors)

  • TYPE 2481

    Pressure Switch

  • Type 3312 Range: 0.07 to 1 Bar

    (Type 3312 Differential Pressure Switch Range: 0.07 to 1 Bar External adjustment and Adjustable Reset Differential. Pressure chambers in 316 Stainless Steel and both connections fitted with 0.5 metres of Stainless Steel clad flexible capillaries connected to remote transmitting diaphragm assemblies System oil filled under vacuum Process connections: 1/4” NPT Female, in UPVC with PTFE transmitting diaphragm protection discs and fitted with 12 hole HALAR (ECTFE) lined mounting rings Seals: PTFE Mounting brackets in polished 316 Stainless Steel fitted to switch and remote transmitters SPDT switch, contact rating 10A at 250V AC Electrical entry: 20mm conduit adapter in 316 Stainless Steel Switch cover in 304 Stainless Steel Max line pressure 11 bar System hydrostatic test: 8 bar for 30 minutes)

  • TYPE 65

    100mm Dia, Diaphragm Pressure Gauge Range: 0-3000mmH20 & 0-30000 Pa Process Connection:318" BSP male, parallel, bottom entry, direct mounting Wetted parts: brass connection with a beryllium copper diaphragm

  • type 70

    Pressure Gauge

  • TYPE 807

    Pressure Switch

  • TYPE PF262A1B/1W22F22B/22S1XA

    Flameproof Pressure Switch Range: 2 to 14 bar Maximum working pressure: 50 bar Process connection: 1/2” BSP male, parallel 316 Stainless Steel with a Nitrile diaphragm Direct mounting Aluminium housing Anodized Black

  • Type 1381

    Pressure Switch

  • Type 1381V

    Pressure Switch

  • 1381

    PRESSURE SWITCH

  • 2382

    Pressure Switch

  • 1381

    Pressure switch

  • Type 1382

    differential pressure switch

  • TYPE:1381

    PRESSURE SWITCH

  • 1381 13C4370050

    Pressure switch

  • A-10

    SWITCH PRESSURE

  • 2042 G4 SERIES

    VALVE PRESSURE REDUCING BRONZE

  • 1392P

    Visual Setting Differential Pressure Switch

  • CX2334

    GAUGE
