Bailey & Mackey - 19D8896095

More products of Bailey & Mackey

• REPLACEMENT UNIT FOR PRESSURE SWITCH SERIAL NUMBER 04 86394 003

  (Type 14P Pressure Switch Range: 0.4 to 4 bar Process Connection: 1/8” BSP male, taper Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile Electrical Connection: 4-pin plug & socket SPDT microswitch)

  Make request
• SENSOR FOR TRANSMITTER PTSPGG1N00 0, PN100 316L

  sensor temp.200°c,7 à 8 bars

  Make request
• Type 1381PV

  Pressure switch

  Make request
• Type 1381

  Pressure Switch Range: 0.2 – 4 bar Process Connection: 1/4” BSP male, parallel Wetted parts: brass connection with a beryllium copper diaphragm Seal: PTFE Switch housing ingress protected to IP65 SPDT microswitch rated 10A @ 250V ac CE marked

  Make request
• Type 1382

  Differential Pressure Switch

  Make request
• TYPE 1382 DIFFERENTIAL PRESSURE SWITCH, 0.2TO 4BAR

  Make request
• 1392P

  Pressure Switch

  Make request
• TYPE 14

  Pressure Switch Range: 0.4 to 4 bar Process Connection: 1/8” BSP male, taper Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile SPDT microswitch

  Make request
• TYPE 2381P

  Twin Circuit Pressure Switch Range: 2 – 28 bar Process Connection: ¾ ”NPT male Wetted parts: brass connection with a beryllium copper diaphragm Seal: Nitrile Electrical Entry: 7-pin plug & socket Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac C/W push on crimp connectors CE marked

  Make request
• TYPE 2382 / 0484792003

  (Type 2382 Twin Circuit Differential Pressure Switch Range: 0.07 – 1 bar Process Connection: 1/4” BSP female, parallel Wetted parts: brass chambers with a beryllium copper diaphragm Seal: Nitrile Switch housing ingress protected to IP65 SPDT microswitches rated 5A @ 250V ac Max line pressure 34 bar C/W wall mounting bracket and push on crimp connectors)

  Make request
• TYPE 2481

  Pressure Switch

  Make request
• Type 3312 13 C5512.12

  Make request
• Type 3312 Range: 0.07 to 1 Bar

  (Type 3312 Differential Pressure Switch Range: 0.07 to 1 Bar External adjustment and Adjustable Reset Differential. Pressure chambers in 316 Stainless Steel and both connections fitted with 0.5 metres of Stainless Steel clad flexible capillaries connected to remote transmitting diaphragm assemblies System oil filled under vacuum Process connections: 1/4” NPT Female, in UPVC with PTFE transmitting diaphragm protection discs and fitted with 12 hole HALAR (ECTFE) lined mounting rings Seals: PTFE Mounting brackets in polished 316 Stainless Steel fitted to switch and remote transmitters SPDT switch, contact rating 10A at 250V AC Electrical entry: 20mm conduit adapter in 316 Stainless Steel Switch cover in 304 Stainless Steel Max line pressure 11 bar System hydrostatic test: 8 bar for 30 minutes)

  Make request
• TYPE 65

  100mm Dia, Diaphragm Pressure Gauge Range: 0-3000mmH20 & 0-30000 Pa Process Connection:318" BSP male, parallel, bottom entry, direct mounting Wetted parts: brass connection with a beryllium copper diaphragm

  Make request
• type 70

  Pressure Gauge

  Make request
• TYPE 807

  Pressure Switch

  Make request
• TYPE PF262A1B/1W22F22B/22S1XA

  Flameproof Pressure Switch Range: 2 to 14 bar Maximum working pressure: 50 bar Process connection: 1/2” BSP male, parallel 316 Stainless Steel with a Nitrile diaphragm Direct mounting Aluminium housing Anodized Black

  Make request
• Type 1381

  Pressure Switch

  Make request
• Type 1381V

  Pressure Switch

  Make request
• PF262A1B/1B22F22B/22S1XA

  Pressure switch

  Make request
• 1381

  PRESSURE SWITCH

  Make request
• 2382

  Pressure Switch

  Make request
• Type 1381X (04 86596 025)

  Pressure Switch

  Make request
• 1381

  Pressure switch

  Make request
• 06 90393004 - Obsolete!!Replaced with "1381"

  Pressure switch

  Make request
• Type 1382

  differential pressure switch

  Make request
• TYPE:1381

  PRESSURE SWITCH

  Make request
• 1381 13C4370050

  Pressure switch

  Make request
• A-10

  SWITCH PRESSURE

  Make request
• 2042 G4 SERIES

  VALVE PRESSURE REDUCING BRONZE

  Make request
