Baelz - Nr. 590-0007 (Compressing Steam)
| Manufacturer | Baelz |
|---|---|
| Part Number | Nr. 590-0007 (Compressing Steam) |
| Inner Code | 4054941 |
| Description | Steam ejector with mounted actuator |
| Custom Code | 84818099 |
| Technical specification | Controllable steam ejector Jetomat, w/o actuator 5.3103, max. 240°C; stroke 22 mm; Ø 10 mm 590-1-DN 80-PN 16/25-Düse 32 mm body/diffuser: GJS-400-18-LT - 5.3103 max. 240°C/22 bar- 50°C/25 bar spindle-Ø 10 mm DN 80, PN 16/25, nozzle 32 mm p01: 6,0 bar g p03: 2,0 bar g p04: 3,2 bar g m01: 1999 kg/h m03: 400 kg/h m04: 2399 kg/h max. admissible delta p actuator: 18 bar Net Weight: 50,6 kg + Best.-Nr. 373-E65-20-30-301 Motorized fail-safe actuator 2000 N; 10/15/30 mm/min; 2-/3 point; 0…10V/4…20mA 373-E65-D-20-30-S21-230 actuating speed adjustable: 10, 15 or 30 mm/min. factory setting: 10 mm/min. crank handle power failure: pushing (spindle moves out / extends) input signal: 0…10 V or 4…20 mA 2- or 3-point selectable output signal: 10…0 V (inverted) incl. actuator yoke and coupling (S21) stroke max. 40 mm, self-adapting silicone-free type IP 66 (vertical mounting) 230 V AC Net Weight: 5,6 kg |
Please contact us to request a price quote for Baelz - Nr. 590-0007 (Compressing Steam), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
