Baelz - 834-001
| Manufacturer | Baelz |
|---|---|
| Part Number | 834-001 |
| Inner Code | 4763803 |
| Description | Pressure limiter TÜV-certified* |
| Custom Code | 90262020 |
| Technical specification | Maximum pressure limiter TÜV-certified* Setting range: 1.2.. 6 bar; operating pressure: 10 bar 834/1-F-SDBAM6 to limit maximum pressure in steam and Hot water systems Sensor housing: X14CrMoS17 - 1.4104 Parts in contact with the medium: metal bellows X6CrNiMoTi17-12-2 - 1.4571 Switch housing: Die-cast aluminum DG Al Si 12 (DIN 1725) Process connection: G 1/2 A, AG electr. Connection: DIN 43650 plug Protection class: IP 54 max. medium/ambient temperature: -20... +70°C Switching difference: manual reset 1 switch: 5 A, 250 V AC inductive Operating pressure: max. 10 bar Vacuum resistance: -1 bar SIL 3 |
Please contact us to request a price quote for Baelz - 834-001, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
