Baelz - 378-ET01-011
| Manufacturer | Baelz |
|---|---|
| Part Number | 378-ET01-011 |
| Inner Code | 4055462 |
| Description | Electrothermal actuator |
| Technical specification | 90 N; 3 min.; Hub 3,5 mm 378-ET01-0,09-3-3,5mm-24 suitable for building on Radiator valves baelz 500… 507 with assembly-friendly First-open function Housing: plastic Connection part: nickel-plated brass Degree of protection: IP 40 (EN 60529) Spring force: 90 N + 20 / -10% Ambient temperature: max. 60 ° C Humidity: 10… 90%, non-condensing Connection cable: 2 x 0.75 mm², HQVV-F white, length 600 mm Thread connection: M 30 x 1.5 Function: closed without electricity (OSG) Continuous current / power: 60 mA / 2 W Voltage: 24 V, 50/60 Hz |
Please contact us to request a price quote for Baelz - 378-ET01-011, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
