Baelz - 373-E45-40-15-171-1 + MP373-E45-1051
| Manufacturer | Baelz |
|---|---|
| Part Number | 373-E45-40-15-171-1 + MP373-E45-1051 |
| Inner Code | 559902 |
| Description | Electric linear actuator with synchronous motor |
| Technical specification | Motorized hoist drive for control operation Positioning electronics for drive control for assembly on baelz control fittings DN 15….150 with thrust-dependent motor limit switches. 373-E45-40-15-S21-2EZ-Fg1-22mm-230 Thrust : 4000 N Actuating speed : 15 mm/min 50 Hz 18mm/min 60Hz Degree of protection: IP 65 Ambient conditions : max. -10°C…+50°C, 0…75% r. F. non-condensing with manual intervention Hood : sheet steel, yellow S21 for DN 15 - 125 : aluminum stand, coupling and fixing screws 2EZ-Fg1k : 2 add. Limit switch for position signaling and 1 remote transmitter 1 kΩ Stroke : 22mm electr. Connection : 3 x M20 x 1.5 Power supply : 230 V, 50/60 Hz + baelz MP373-E45-PEL-230-M Input/Output: 0…10V, 0(4)…20mA selectable Delivery condition: 0…10 V Ambient temperature: max. -10…+50°C Drive must be equipped with a 1kΩ transmitter 230V, 50/60Hz |
| Weight | 1 |
Please contact us to request a price quote for Baelz - 373-E45-40-15-171-1 + MP373-E45-1051, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
