Baelz - Order no. 340-2465
| Manufacturer | Baelz |
|---|---|
| Part Number | Order no. 340-2465 |
| Inner Code | 4529015 |
| Description | Straight through control valve |
| Technical specification | valve, fully assembled 5,3103, max. 350°C, stroke 22 mm; without drive 340-2-BK-SS-DN 125-PN 16-Kvs 200 Package/case: GJS-400-18-LT - 5.3103 max. 350°C/10.2 bar - 50°C/16 bar Spindle diameter: 10 mm DN 125, PN 16, Kvs 200 Max. permissible delta p: 2.8 bar Bestr. -No. 373-E45-40-15-5003 Digital motor lift drive steadily 4000 N; 15 mm/min; 0/2-10V or 0/4-20 mA 373-E45-40-15-S21-2ez-FG5K-7020A-115 1 piece self-adaptation 1 input signal: 0/2... 10 V or 0/4... 20 mA delivered condition: 0... 10 V 2 output signals: output 1:0... 10 V and output 2:0... 20 mA or output 1:2... 10 V and output 2:4... 20 mA Supplied condition: 0... 10 V and 0... 20 mA 1 digital input freely adjustable via software 2 relays freely adjustable via DIP switches auxiliary changeover contacts 12... 250 VAC Interface: RS 485 Modbus RTU 2 additional Limit switch, 1 remote control 5 kOhm incl. drive stand and clutch (S21) For valves with a spindle diameter of 10 mm IP 65; stroke max. 40 mm 115 V, 50/60 Hz Net weight: 8.3 kg The Baelz 373-E45 drive is a replacement for no longer available drive belz 373-E4 |
Please contact us to request a price quote for Baelz - Order no. 340-2465, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
