Badger Meter - Typ RC250 (807)

Manufacturer Badger Meter
Part Number Typ RC250 (807)
Inner Code 3397996
Description REGELVENTIL
Technical specification 1/2" control valve type RC 250 (807) Valve body: passage, rod material, 316L SST Connection: 1/2" NPT internal thread Valve top: 316SST 592 material double pack 1/8" NPT control port Spindle sealing: double roof seals, material PTFE/PFA Inner set: size “H” linear, Kvs 0.11 Stellite cone/seat stellated 316 SST 511 Actuator: Pneumatic, spring closes, type 754, ATO, 316L 0.2-1.0 bar, 1/4" BSP signal Assembly grease: contains silicone “Dow 111
Weight 1

Please contact us to request a price quote for Badger Meter - Typ RC250 (807), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Badger Meter-Typ RC250 (807) price

More products of Badger Meter

  • RCDL LCR

    Register with pulse output, Electronic counter LCR type with an LCD display and, pulse output above for OG-Baureihe.Anzeige 1: resettable totalizer or flow indication programmable, Format xxxx.x. Display 2: Non-resettable totalizer, 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64 For counter Size: M25-M35-M40-M70-M120-M170 Pulse output: NPN, MOSFET 40V / 2A Pulse factor: 0.01-99.99 Pulse length: 10ms (2ms, 20ms, 40ms) Ext.Stromversorg. : 8-24VDC Pulse output PPL: 0,01-0,1-1-10-100 Dosing control: 0.01 to 999.99 Preliminary circuit: from 0.00 to 99.99 Switching output: NPN, MOSFET 40V / 2A

  • RCDL LCR REGISTER MIT IMPULSAUSGANG U. STROMAUSGANG 4-20MA

    Electronic counter LCR type with an LCD display, Display 1: resettable totalizer or Flow display programmable, Format xxx.xx. Display 2: Non-resettable totalizer 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA

  • RCDL LCR REGISTER OHNE IMPULSAUSGANG

    Electronic counter LCR type with an LCD display, for the OG series Display 1: resettable totalizer or Flow display programmable, format xxxx.x Display 2: Non-resettable totalizer 14 digits Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64

  • RCDL M25

    3/4 "or 1" PPO Viton without pulse, fluid meter RCDL M25 without construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, standing

  • RCDL M25 1"

    Vectra Viton pulse PFT-2 reed contact Liquid meter RCDL M25 without construction. Materials and technical data: Housing: Bronze Measuring chamber: Vectra O-rings: Viton Measuring range: 3-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: ° C Connection: R 1 "outside Installation length: 190 mm Installation position: horizontal, standing 604011 Pulse PFT-2 reed contact about 52 PPL

  • RCDL M25 3/4" ODER 1" PPO VITON OHNE IMPULSGEBER

    (Liquid meter RCDL M25 without Construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, vertical)

  • RCDL M25, WITH PULSE- TRANSMITTER PFT-1E - 52,4 PULSE/LITER SETUP

    Housing : Bronze Chamber : Noryl (PPO) O-Rings : Buna Flowrange : 1-100 l/min Accuracy : +/- 1,5 % of value p-max : 10 bar t-max : 50 °C Connection : Threads 1" male Laylength : 190mm Pulsoutput : Open Collector NPN Scale Factor : 0.00001 to 0.9999 Supply : 12-24 VDC Pulsoutput : S/N : Part-Nr. 141158

  • KT M2000 50

    MID M 2000 mit Flansch DN 50 1.4571

  • 106126

    Oval wheel counter

  • PN : MID M 1000, Type : Typ ModMAG M1000

    magnetic inductive flowmeter

  • 7500P

    Electromagnetic Flow Meter

  • XMT-DS-00738

    Pulse Flow meter

  • P/N: 9008527 Type: MID M 1000 DN 50/16

    Magnetisch-Induktiver-Durchflußmesser

  • 9008563 (MID M 1000)

    Magnetisch-Induktiver-Durchflußmesser

  • 102460 LM OG-PNDA electronic preset counter

    Elektronischer Vorwahlzähler

  • PFT-2 E

    Impulsgeber

  • PTF-1E

    Signal Transmitters

  • M1500AA DN50

    magnetic flow meter
