Badger Meter - B102101
| Manufacturer | Badger Meter |
|---|---|
| Part Number | B102101 |
| Inner Code | 331977 |
| Description | Einbauzähler mit Impulsgeber für Schmieröl |
| Custom Code | 9028 20 00 |
| Technical specification | LM OG 1/2" BSP ALU LCP Buna 1-35 l/min with Reed contact 100 PPL Built-in counter with pulse generator for lubricating oil Materials and technical data Measuring principle: Oval wheel counter Housing: aluminum Oval wheels: plastic (LCP) Seal: Buna Measuring range: 1 - 35 l/min Measurement accuracy: ± 0.5% of the measured value Viscosity range: 8-5000 mPas p-max: 100 bar t-max: 50°C Protection class: IP 42 Connection: 1/2" BSP female thread Pulse generator (blue) Pulse output: 1x100ppl, reed |
| Weight | 1 |
Please contact us to request a price quote for Badger Meter - B102101, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
