Avs Römer - KLD20S-BD3-3/4"-SS-230V AISI316
| Manufacturer | Avs Römer |
|---|---|
| Part Number | KLD20S-BD3-3/4"-SS-230V AISI316 |
| Inner Code | 4751205 |
| Description | Stainless steel ball valve |
| Custom Code | 84818081 |
| Technical specification | Technical Specification Pressure range: 0-1 0 bar Connection: Female thread 1 /2" - 1 " acc. to DIN ISO 228 Working time 0-90°: 5-7s Standard voltages: 24VDC (Voltage range: 1 8-24VDC) 230V/50Hz (Voltage range: 96-265V/50Hz) Power: 4W (24VDC) 5W (230V/50Hz) Media temperature: -20...+1 00°C Ambient temperature: -20...+45°C Body: Stainless steel, AISI31 6 Ball: Stainless steel, AISI31 6 Stem: Stainless steel, AISI31 6 Ball seats: PTFE Stem seats: FKM/PTFE Actuator housing: ABS-plastic, PA-777D Protection class: IP67 Electrical connection: 0,8m cable, 3-wires |
Please contact us to request a price quote for Avs Römer - KLD20S-BD3-3/4"-SS-230V AISI316, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
