Aventics - P/N: 0820058026 Type: TC15-5/2XX-SR-024DC-I-FORM-C-SGL
| Manufacturer | Aventics |
|---|---|
| Part Number | P/N: 0820058026 Type: TC15-5/2XX-SR-024DC-I-FORM-C-SGL |
| Inner Code | 12900 |
| Description | Directional valve |
| Custom Code | 84812090 |
| Technical specification | Version: Spool valve, zero overlap Sealing principle: Soft sealing Mounting on manifold strip: P-strip Working pressure min./max.: See table below Control pressure min./max.: See table below Ambient temperature min./max.: -10°C / +50°C Medium temperature min./max.: -10°C / +50°C Medium: Compressed air Max. particle size: 5 µm Oil content of compressed air: 0 mg/m³ - 5 mg/m³ Nominal flow Qn: 1500 l/min Connector standard: ISO 15217 Protection class with connection: IP65 Duty cycle: 100 % Generic emission standard in accordance with: EN 50081:1992 Mounting screw tightening torque: 2.5 Nm Weight: See table below Materials Housing: Polyamide, fiber-glass reinforced Seals: Acrylonitrile Butadiene Rubber; Hydrogenated nitrile butadiene rubber Front plate: Polyamide, fiber-glass reinforced |
| Weight | 0.235 |
Please contact us to request a price quote for Aventics - P/N: 0820058026 Type: TC15-5/2XX-SR-024DC-I-FORM-C-SGL, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
