Aventics - 0822241403
| Manufacturer | Aventics |
|---|---|
| Part Number | 0822241403 |
| Inner Code | 4983767 |
| Description | Tie rod cylinder |
| Custom Code | 84123100 |
| Technical specification | StandardsISO 15552 Piston Ø40 mm Stroke100 mm Functional principleDouble-acting CushioningPneumatic adjustable cushioning Magnetic pistonPiston without magnet Environmental requirementsIndustry standard, Heat resistant Piston rodsingle ScraperHeat-resistant scraper Pressure for determining piston forces6,3 bar Retracting piston force660 N Extracting piston force790 N Min. ambient temperature-10 °C Max. ambient temperature150 °C Working pressure min.1.5 bar Working pressure max10 bar PortsG 1/4 Piston rod threadM12x1,25 Cushioning length15 mm Cushioning energy9 J Weight 0 mm stroke0.67 kg Weight +10 mm stroke0.03 kg Stroke max.1900 mm MediumCompressed air Min. medium temperature-10 °C |
Please contact us to request a price quote for Aventics - 0822241403, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
