Aventics - 0821300858
| Manufacturer | Aventics |
|---|---|
| Part Number | 0821300858 |
| Inner Code | 535169 |
| Technical specification | NL6-FRE-G100-GAU-SSS-HO-40,00 Filter pressure regulator, Series NL6-FRE Reservoirreservoir, metal, with inspection glass PortG 1 Nominal flow Qn15000 l/min Filter porosity40 µm Condensate drainsemi-automatic, open without pressure Pressure gaugewith pressure gauge Working pressure min.1.5 bar Working pressure max16 bar Min. ambient temperature-10 °C Max. ambient temperature60 °C Regulation range min.0.5 bar Regulation range max.10 bar Lock typenot lockable Type1-part TypeCan be assembled into blocks Pressure supplysingle Mounting orientationvertical Regulator typeDiaphragm-type pressure regulator Regulator functionwith relieving air exhaust Max. Internal air consumption0.5 l/min Filter elementexchangeable Filter reservoir volume125 cm³ Max. achievable compressed air class acc. to ISO 8573-1:20107 : 7 : - MediumCompressed air, Neutral gases |
| Weight | 1 |
Please contact us to request a price quote for Aventics - 0821300858, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
