Aventics - 0820055501
| Manufacturer | Aventics |
|---|---|
| Part Number | 0820055501 |
| Inner Code | 1861756 |
| Description | Directional Valve |
| Custom Code | 84812090 |
| Technical specification | Version Spool valve, zero overlap Pilot external, internal Sealing principle soft sealing Blocking principle Single base plate principle Working pressure min./max. -0.9 bar / 10 bar Control pressure min./max. 2.5 bar / 10 bar Ambient temperature min./max. +0°C / +50°C Medium temperature min./max. +0°C / +50°C Medium Compressed air Max. particle size 5 µm Oil content of compressed air 0 mg/m³ - 5 mg/m³ Protection classwith electrical connector/plug IP 65 Protective circuit Z-diode Protected against polarity reversal Status display LED Yellow Duty cycle 100 % Generic emission standard in accordance with EN 50081-1 Generic immunity standard in accordance with EN 50082-2 Mounting screw cross recessed DIN EN ISO 4757-Z1 mounting screw tightening torque 1.3 Nm Materials: Housing Polyamide, fiber-glass reinforced Seals Acrylonitrile Butadiene Rubber |
| Weight | 0.08 |
Please contact us to request a price quote for Aventics - 0820055501, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
